Series-20 ´white´ / ´black´ - Solar Panels
Walkable flat deck mounting solar panel -
powerful, extremely robust & salt water resistant
The solar panels of the series-20 ´white´ or ´black´ (no white rim) are lightweight, compact and extremly powerful. Monocrystalline PERC high-performance solar cells are protected in an EVA laminate & ETFE coatings against weathering - sup. by a sandwich core. High charging current in diffuse light conditions or even in winter.
The solar panels are designed for harsh marine and salt water use. Cable outlets are screwed to the mounting plate, complete sealed & 100% saltwater proof. 12 dif. sizes.
Read more
Series-40 ´black´ - Solar Panels
Walkable flat deck mounting solar panel with back side cable outlet
Solar panels of the series-40 ´black´ are lightweight, very compact & extremly powerful. In contrast to the series-20, the cable outlet of the series-40 is mounted at the back side. This enables completely flat mounting on deck, on buoys etc. without cables visable. Monocrystalline PERC high-performance solar cells are protected in an EVA laminate & ETFE coatings against weathering - supported by a sandwich core. High charging current in diffuse light conditions or even in winter. 12 dif. sizes.
Read more
TX+ (Extension) - Solar Panels
Extension for Bimini / Sprayhood mounting, fabric edged solar panels with additional socket
Lightweight panels with textile frame made of high-quality marine tarpaulins and an additional socket for module extension. Simply insert further TX or TX+ solar panels up to 16A total current. TX modules have been specially developed for mounting on Bimini or Sprayhood. They are also based on laminated high-performance solar modules with the accustomed SunWare quality. The use of these modules enables an increased use of green-energy on otherwise unused areas. Mounting with LOXX as all TX-serie
Read more
RX - Solar Panels
Mobile Plug&Play charging solution, fabric edged solar panels, 2-wing foldable
Plug-in solution based on laminated high-performance solar modules with the accustomed SunWare quality. 5m supply cable with SureSeal plug on the solar panel, suitable for the accompanying 12V/24V FOX-062 charge controller. Simply plug the FOX-062 into the socket of the vehicle and the battery will be charged. The roof surfaces on the vehicle are already occupied, rather the vehicle in the shade and only the panel stands in the sun - a simple and comfortab solution. To be stowed away easily.
Read more
24V - Solar Panels
SunWare offers various solar solutions for 24 V systems
(´black´and / or ´white´ front side)
The following solar panels are available for 24 V systems:
Series-20 / -40 (Umax: ~43V / Uoc: ~53V),
-> 60 Wp, 772 x 493 mm, 2.6 kg
-> 90 Wp, 1119 x 493 mm, 3.6 kg
Series-TX (Umax: ~39V / Uoc: ~49V),
-> 90 Wp, 873 x 826 mm, 4.2 kg
-> 120 Wp, 1106 x 826 mm, 5.1 kg
-> 180 Wp, 929 x 1590 mm, 8.2 kg
-> 240 Wp, 1164 x 1590 mm, 10.9 kg
Of course it is always possible to charge 24 V systems by producing a series connection of 12 V panels.
Read more
FOX-X20 - Charge Controller, 22A, 12V/24V
Solar charge controllers with LED and external display (FOX-MD1)
Charge controllers with LED, showing the battery condition & system status. With adaptive total discharge protection to monitor and protect the battery against total discharge. For solar panel currents up to 22A. Suitable for AGM, GEL and Lead-acid batteries. FOX-320/220 can simlpy be ´plug&play´ connected to the external FOX-MD1 display (data cable). Showing exact voltages, currents and allows to program various parameters, e.g. as battery type and charge ratios. FOX-320: for 2 battery systems.
Read more
FOX-X60 - Charge Controller, 22A, 12V/24V
Solar charge controllers with wide, integrated LCD-display
Programmable charge controller with integrated LCD display, 1 or 2 seperate battery systems. FOX-360/260 are characterized by its easy use and a compatibility with AGM, Gel, LeadAcid, LiFePO4 batteries. Display and setting options for battery voltage, charging current, generated panel current, power consumption, battery charge status as bar graph-, charge ratio B1/B2 is adjustable. The controllers are designed for up to 22A charge current incl. over charge protect. FOX-360: for 2 batterie syst.
Read more
FOX-062 - Charge Controller, 6,6A, 12V/24V
Mini ´Plug&Play´ solar charge controller with LED
Plug & Play "in cable"-solution with mini solar charge controller, adjustable to battery type, and car socket plug with integrated fuse at one side. On the solar input side there is a SureSeal socket, a module cable with SureSeal connector can be plugged. The FOX-062 has an integrated LED and reverse current protection. A charging efficiency of 98% is achieved. In contrast to MPPT controllers this type of controller has an up to 20% higher efficiency when using 12V or 24V Solar modules.
Read more
